Product Features
Highly compatible with new energy vehicle charging interfaces/protocols.
Multi-intelligent detection: real-time voltage/current monitoring, precise power calculation & safety protection.
1.9" display: real-time standby/charging/fault status & parameters.
Multiple authorization modes: plug-and-charge, card swipe, APP scheduling.
Charging modes: auto-full, timed charging.
OCPP 1.6 protocol enhances flexibility, scalability & data security.
Load balancing system optimizes power distribution across multiple chargers for stable operation.
Remote O&M platform enables device health diagnosis, fault (early warning) & OTA upgrades to reduce costs.
Compliant with ETL&CETL, FCC, IC, TÜVmark, CE,CCC.
Applications
Suitable for home use in residential quarters, private residences, factories and other places.
Suitable for commercial use in office buildings, urban complexes, etc.
Suitable for parking lots, public charging station,etc.
Suitable for New Energy Vehicle 4S Stores, workshop debugging, driving school, etc.
Product Parameters
| Item | ZB14-X007KXX-X001 | ZB14-U09K6XX-X001 | ZB14-X011KXX-X001 | ZB14-X022KXX-X001 |
| Input Voltage | AC220V±20%(CN) AC230V±10%(EU) AC240V±15%(US) |
AC240V±15%(US)
| AC240V±15%(US) AC380V±20%(CN) AC400V±10%(EU) | AC380V±20%(CN) AC400V±10%(EU) |
| Input Frequency | 50/60Hz±1Hz |
| Output Power | 7kW | 9.6kW
| 11kW | 22kW |
| Current | 32A | 40A | 48A/16A(3-phase) | 32A(3-phase) |
| Display Size | 1.9inches |
| Communication | RFID；WiFi&Bluetooth；4G；Ethernet
|
| Gun Cable Length | 3.5m/5m/7m/7.5m |
| Temperature/Humidity | -30~+50℃/5%~95%RH |
| Protection | IP65 |
| Appearance Size | 368.17mm×255.5mm×96.59mm |
| Product Weight | <7.2KG |
| Leakage Protection | Type A+DC6mA(CN)/Type A RCBO AC 30mA +IΔdc 6mA(EU)/CCID20(US) |
